all stainless pressure gauge

all stainless pressure gauge

Item:SS4-1.6MPA
PDF:no !pfd

 Specification:

Description:


Normal Size:

1.5"(40mm),2.0"(50mm),2.5"(63mm),

3"(75mm),4"(100mm),6"(150mm).

Pressure Range:-1Bar(-30"Hg)-0-1000Bar(15000Psi)
Accuracy:¡À1%,¡À1.6%
Operating temperature:-20¡ãC to +60¡ãC
Case:steel , Plastic, Stainless Steel
Bezel:steel , Stainless Steel
Bourdon tube:

Copper alloy or Stainless steel

<100Bar: C-Type

¡Ý100Bar: Helical Type

Connection:Brass or stainless steel
Movement:Brass or stainless steel
Dial:Aluminum
Pointer:Aluminum
Window:Plastic , glass
Thread:

1/8",1/4", 3/8",1/2";

PT(BSPT,ZG),BSP(G,PF),NPT etc.
